functional characteristics
Host low power consumption design, Chinese LCD display, real-time display of sensor collection data, current GPS location (longitude and latitude), battery power, alarm function, current date, storage capacity and stored data quantity and other information, and can set the data storage and transmission time interval.
For the long-time online measurement, the timing collection time can be set for 5 minutes ~99 hours, and the data can also be manually collected, automatically recorded and stored.
With GPS positioning function, data automatic collection, real-time field display of the location of the geographic coordinates (latitude and longitude information) and save.
Built-in SD card, can save up to 40 million sets of data, you can be viewed on the data on the host, or imported into the computer to view.
The data saved in the SD card is not lost after an unexpected power failure.
The probe is consistent and can be connected to more than a dozen sensors. The sensor interfaces with different meteorological parameters can be interchangeable without affecting the accuracy.
Low power consumption design, the lowest running time power consumption is only 300uA.
▌ Product Description
Manage cloud platform features (optional)
The own instrument cloud management platform includes C / S architecture, which can import the data of all portable device SD card into the instrument cloud data management platform, and can be synchronized to the instrument cloud, with data backup against loss, and viewing the operation mode includes the web end and mobile end (Android).
Show the process curve trend of each parameter, maximum value, minimum value, average value display view, zoom in and out function.
The data can be uploaded to the instrument cloud data management platform. Data within the platform can be downloaded, analyzed, and printed.
Users can configure the sensor alarm conditions for the equipment, and preset the alarm configuration of several common crops.
The platform supports device data storage and provides sufficient capacity for long-term storage.
The platform provides curves and tables and other report forms for device data, and the data can be imported and imported.
Data evaluation: the lowest maximum overlimit value can be set and data warning analysis can be conducted automatically.
Software can be upgraded online.
technical parameter
Solar panels: 10WP
Adapter power supply: DV9V / 1A
Complete machine power: W1.5W
Coordinate accuracy: 3 decimal places: ±: 0.05 points; N: 0-90: °: E 0-180.
Atmospheric temperature: Measurement range: -4or-i2or resolution: 0.1 begging precision: ± 0.4 fence
Light intensity: Measurement range: 0-200000LUX resolution: 1LUX precision: ± 2%
Wind direction: Measurement range: 0-360° Resolution: 1. accuracy:±3.
Other optional sensors: soil moisture, soil temperature, atmospheric pressure, radiation, dew point, direct
radiation, choose 3 function is enough, if more will useless and waste the battery
